347 Stainless Steel Strip

347 Stainless Steel Strip

Alloy 347 Stainless Steel Strip

UNS N34700
W.Nr 1.4550

Applicable Specifications

Strip and Foil: AMS 5512, ASTM A240, MIL-S-23196

Applications

Annealing covers, High-temperature tempering equipment, Diesel and heavy-duty automotive exhaust, Firewalls, Stack liners, Boiler casings, Welded pressure vessels, Aircraft components, Bellows, Oil refinery equipment, Springs

Description

Type 347 is a stabilized austenitic stainless steel, similar to type 304, but alloyed with Niobium (Columbium) for use in applications involving continuous or intermittent service at 800-1500°F (427-816°C). 347 stainless has excellent resistance to oxidation, even surpassing that of 321 in strong oxidizing conditions. The alloy maintains resistance to intergranular corrosion, while also possessing good creep strength compared to other 300 series stainless steels. The alloy is strengthened only through cold work and can be fabricated, machined, and welded via most conventional processes.

Industries Supplied

Aerospace, Oil & Gas, Chemical Processing, Food Processing, Waste Treatment

Nominal Composition

C: 0.08 max
Mn: 2.00 max
Si: 1.00 max
P: 0.045 max
S: 0.030 max
Cr: 17.0 – 19.0
Ni: 9.0 – 12.0
Nb(Cb): 10*C – 1.00
Fe: Balance
N: 0.10 max

Physical Properties

Density: 0.288 lb/in3, (7.96 g/cm3)

Modulus of Elasticity (E):
At 70°F (20°C): 28.0 x 103 ksi (193 GPa)

Modulus of Rigidity (G)
At 70°F (20°C):  11.2 x 103 ksi (78 GPa)

Coefficient of Expansion:
11.4 µin/in.-°F (32-1500°F)
20.5 µm/m-°C (0-871°C)

Electrical Resistivity: 28.4 µohm-in, (72 µohm-cm)

Thermal Conductivity:
113 Btu-in/ft2hr-°F, (212°F)
16.3 W/m-°C (100°C)

Applicable Specifications

Strip and Foil: AMS 5512, ASTM A240, MIL-S-23196

Typical Mechanical Properties

  • Annealed
    • Heat Treatment: 1750-2150°F (954-1175°C)
    • Tensile Strength: 90 – 110 ksi (620-760 MPs)
    • Suggested Operating Conditions: up to 1500°F (816°C)
